Specification

General

Model Variants
NEO-X1
• AMD Ryzen™ 9 9955HX
• NVIDIA® GeForce RTX™ 5060 Ti 8GB

NEO-X1 Pro
• AMD Ryzen™ 9 9955HX3D
• NVIDIA® GeForce RTX™ 5070 12GB

Available Configurations
• 32GB or 64GB DDR5 memory
• 1TB or 2TB SSD storage
Processor
AMD Ryzen™ 9 9955HX / Ryzen™ 9 9955HX3D
• Zen 5 architecture
• 16 cores / 32 threads
• 2.5GHz base clock
• Up to 5.4GHz boost clock
• TSMC 4nm CPU process and 6nm I/O die
• 1,280KB L1 cache
• 16MB L2 cache
• NEO-X1: 64MB L3 cache
• NEO-X1 Pro: 128MB L3 cache with AMD 3D V-Cache™ technology
Graphics
Integrated AMD Radeon™ 610M Graphics
• 2 graphics cores
• Up to 2,200MHz graphics frequency

NEO-X1: NVIDIA® GeForce RTX™ 5060 Ti
• 4,608 CUDA cores
• 8GB GDDR7
• 128-bit memory interface
• 28Gbps memory speed
• Up to 759 AI TOPS

NEO-X1 Pro: NVIDIA® GeForce RTX™ 5070
• 6,144 CUDA cores
• 12GB GDDR7
• 192-bit memory interface
• 28Gbps memory speed
• Up to 988 AI TOPS
Performance Modes
Three Selectable Processor Power Modes
• Silent Mode: 54W
• Balanced Mode: 85W
• Performance Mode: 160W
• Peak Processor Power: Up to 170W
Cooling System
Liquid CPU Cooling System
• Three system cooling fans
• Two top cooling fans
• One bottom cooling fan
Power Delivery
Internal SFX 850W Power Supply
• 80 PLUS Gold certified
• 13-phase motherboard power design
• AC power input
• Built-in CMOS battery
Memory
Dual-Channel DDR5-5600 Memory
• 2 x DDR5 SO-DIMM slots
• 32GB and 64GB configurations available
• Maximum supported capacity: Up to 96GB
• Maximum memory speed: Up to 5,600MT/s
Storage
Dual M.2 NVMe Storage
• 1TB and 2TB PCIe 4.0 M.2 2280 SSD configurations available
• Slot 1: M.2 22110/2280, supporting PCIe 5.0 x4
• Slot 1 is the BIOS-priority boot drive slot
• Slot 2: M.2 2280, supporting PCIe 5.0 x4
• Maximum supported capacity: Up to 8TB per slot
• Maximum total storage capacity: Up to 16TB
Video Output
Four-Display Output Support
• Maximum supported resolution: Up to 8K
• Dedicated graphics output is prioritised by default

Motherboard Outputs
• 1 x HDMI 2.1 TMDS, up to 4K@60Hz
• 1 x DisplayPort 1.4, up to 8K@60Hz

Dedicated GPU Outputs
• 1 x HDMI 2.1b, up to 8K@60Hz
• 3 x DisplayPort 2.1b, up to 8K@60Hz
Network
Wi-Fi 7
• AMD RZ717 wireless module with MediaTek MT7925 chipset
• Maximum theoretical wireless speed: Up to 2.9Gbps
• External antenna connectors

Bluetooth 5.4

2.5G Ethernet
• 1 x 2.5G RJ45 Ethernet port
• Realtek RTL8125 Ethernet controller
Front Panel I/O
• 2 x USB-A 2.0, up to 480Mbps
• 1 x USB-C data port, up to 5Gbps
• 1 x 3.5mm CTIA audio combo jack
• 1 x power button with white LED
Rear Panel I/O
• 2 x USB-A 2.0, up to 480Mbps
• 2 x USB-A 3.2 Gen2, up to 10Gbps
• 1 x USB-C data port, up to 10Gbps
• 1 x HDMI 2.1 TMDS, up to 4K@60Hz
• 1 x DisplayPort 1.4, up to 8K@60Hz
• 1 x dedicated GPU HDMI 2.1b, up to 8K@60Hz
• 3 x dedicated GPU DisplayPort 2.1b, up to 8K@60Hz
• 1 x 2.5G RJ45 Ethernet port
• 1 x 3.5mm microphone input
• 1 x 3.5mm line-out
• 1 x 3.5mm line-in
• External antenna connectors
• 1 x AC power input
Design & Materials
14.6L Compact Metal Chassis
• Dimensions without handles: 350 x 165 x 265mm
• Dimensions with handles: 350 x 165 x 310mm
• Net weight: Approx. 7kg
• Metal chassis with painted finish
• Gray and green color scheme
Operating System & Software
Windows 11 Pro
• Default system language: English
• Supports 14 system languages
• Microsoft Office 365 not included
• GMKtec Claw system utility included
Package Contents
• GMKtec NEO-X1 Series Mini PC
• AC power cable
• HDMI cable
• External antenna
• User manual
• Warranty card
• Keyboard and mouse not included
Packaging
• Package dimensions: 443 x 260 x 435mm
• Gross package weight: Approx. 9kg
Warranty & Operating Environment
1-Year Limited Warranty
• Operating temperature: 0°C to 40°C
• Certifications: CCC, CE, FCC, RoHS, MIC and CEC
